Dirt King Stage 2 Mid-Travel Lift Kit for 2019–2026 Chevrolet & GMC 1500 Trucks – Includes Adjustable 2.5″ DCA Coilover Shocks

Description

Transform your GM 1500 by eliminating front-end rake and achieving a leveled lift with the Dirt King Prerunner Kit. This package includes Dirt King’s 4130 Upper Control Arms, 2.5 DCA Front Coilovers, and 2.5 DCA Rear Shocks—all expertly tuned for off-road capability while not compromising on-road comfort. Equipped with high-speed and low-speed compression adjusters, these shocks offer the flexibility to fine-tune ride quality across any terrain or driving style. It’s the perfect choice for those looking to enhance their vehicle’s off-road performance and ride quality.

  Features

• DCA Remote Reservoirs: Remote reservoir equipped with dual compression adjusters allowing for high-speed and low-speed compression adjustments.
• Optimized Lift and Ride Comfort: With vehicle-specific valving, the shocks are expertly tuned for optimal ride quality on both city streets and rugged trails, all while maintaining a leveled lift.
• Enhanced Suspension Geometry: Upper control arms improve caster settings and pivot angles for better handling and increased articulation.
• Increased Suspension Travel: Allows for higher articulation and improved damping on uneven terrains.
• Durable Construction: The upper control arms are professionally MIG welded using 4130 chromoly tubing and finished with a black powder coat.
• High-Quality Components: Aluminum shock bodies for cooler operation and corrosion resistance.
• Maintenance-Free Bushings: Probearing SilentSpin bushings offer a free-spinning inner sleeve without the need for grease.
• Rebuildable and Serviceable: All components are rebuildable or replaceable; tools and replacement parts are available from Dirt King.
• Direct Bolt-On Replacement: Uses factory mounting locations for straightforward installation.

 Specifications

Front Lift Height

• Standard Models:
○ Out of the Box: Provides 3″ of lift (levels vehicle).
○ Max Recommended Setting: Up to 3.5″ of lift.

• Trail Boss / ZR2 / AT4 / AT4X Models:
○ Out of the Box: Provides 1.5″ of lift.
○ Max Recommended Setting: 1.5″ of lift (Do not exceed to maintain ride quality)

Rear Lift Height

• Standard Models:
○ Out of the Box: Factory height is retained.
○ Maximum Recommended Lift Block or Mini Pack.

• Trail Boss / ZR2 / AT4 / AT4X Models:
○ Can use factory blocks or add Deaver Mini Pack.
○ Benefit: Levels the vehicle and optimizes ride quality.

Additional Specifications

• Track Width: Stock
• Maximum Backspacing: 4.75″
• Minimum Rim Size: 17″
• Shock Bodies: 2.5″ hard-anodized 6061 aluminum
• Shock Shafts: Induction-hardened 7/8″

 What’s Included
• Dirt King 4130 Chromoly Upper Control Arms
• Dirt King 2.5 DCA Front Coilovers
• Dirt King 2.5 DCA Rear Shocks
• All Necessary Mounting Hardware
• Dirt King Sticker Pack
• Installation Instructions
